Dried, natural quartz sands
Silica or also called quartz sand is sorted by wet and dry sieving processes. Our Quartz Q silica sands are fire-dried in industrial process. Quartz Q has a hygiene certificate for building products and filtermedia. It is available in 20 standard main fractions, other granulations on request.
It is mainly used for applications as:
Filter medium for water processing plants. As a filler in resin bound flooring systems, based on epoxy-based resins, polyurethanes or methyl methacrylate. Also finds it's application in so-called cement-based dry-mix mortar systems, as a dry filler. This to compose excellent products as plasters, concrete, cement based floorings, mortars or tile clay. Quartz Q can also be used for decorative or functional prefab in building elements.
Dried sand is also used in concrete products, sport fields, wet-blasting, water filtration, roofing systems (protection and isolation), gardens, terraces, children playgrounds, roads and aquariums.
Our sand has a high abrasion resistance and good natural strength parameters.
- Technical specifications:
- Quartz Hardness (Mohs): 7
- Density: 2,65 g/cm³
- Humidity: 0,1%
- Weight compact: 1,55 t/m³
It is packed in 25 kg PE ventile bags / Big Bag of 1000 kg / 25 kg paper bags on request
Available standard granulations
- QD 0,1-0,2 mm
- QS 0,1-0,3 mm
- QQ 0,1-0,4 mm
- QQ 0,1-0,5 mm
- QQ 0,2-0,6 mm
- QQ 0,2-0,8 mm
- QQ 0,4-0,9 mm (before 0,4-0,8)
- QQ 0,5-1,0 mm
- QS 0,8-1,0 mm
- QS 0,7-1,2 mm
- QS 0,8-1,2G mm
- QS 1,0-1,6 mm
- QQ 1,0-1,7 mm
- QQ 1,0-2,0 mm
- QQ 1,0-2,2 mm
- QQ 1,6-2,2 mm
- QQ 2,0-3,0 mm
- QQ 2,0-4,0 mm
- QS 3,0-5,0 mm
- QS 4,0-6,0 mm
- QS 5,0-8,0 mm
 |
 |
 |
 |
||
 |
Technical datasheet Leaflet Blue Quartz Q |  |
 |
 |
|
 |
Technical datasheet BW Quartz Q |  |
 |
 |
|
 |
Sieve analysis all granulations |  |
 |
 |
|
 |
